GSMX120 - Linear stepper stage

★Achieving market requirements, improving efficiency for customers.
★Space saving, high positioning accuracy and good collocation.
★ Providing with the advantages of stepper motor which can be partition positioning directly and does not require an external position feedback mechanism.
★ Various option which can collocate with stepper motor and stepper servo drive.

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Update：2023.03.22

Model No.			GSMX120-40-A-DX	GSMX120-40-I-DX
Syetem			Open loop	Closed loop
Mechanical Spec.	Table Size (mm)		120 X 120
	Overall Width (mm)		131
	Overall Height (mm)		35
	Travel Stroke (mm)		40
	Stage Material / Surface Treatment		Aluminum Alloy / Anodized
	Rail		GS09N
	Main Unit Weight (Kg)		1.5
Precision Spec.	Resolution (µm)		-	1
	Max. Speed (mm / sec)		200	200
	Positioning Presion (µm)		50	10
	Repeatability Precision (µm)		± 5	± 1
	Load Capacity (Kgf)		6
	Parallelism (µm)		30
	Dynamic Parallelism (µm)		10
	Thrust (N)		20
Electrical Spec.	Driver Brand / Model		Oriental / CVD223BR-K	GMT / i-SERVO-ST-42M-GM
	Sensor	Origin Sensor	Photoelectric sensor GMT-sensor
		Limit Sensor	Photoelectric sensor GMT-sensor
		Power Voltage	24V ± 10%
		Control Output	NPN open collector output under 24V 8mA
		Output Control	Testing (sensing)：output transistor OFF (closed)
	Stage Side Connector		15-Pin male end connetor D-SUB
	Controller Side Connector		N / A
	Current		2A
	Electrical resistance		1.8 ohm
	Inductance		1.84 mh
	Phase		2 phases

Axis Definition

GMT has defined different axis as the following figuration according to the movement direction:

Horizontal movement direction is X and Y axis.

Vertical movement direction is Z axis.

Movement around X, Y, Z axis is defined to α axis, β axis, and θ axis.

Green arrows present the specified axis movement direction.
